Introduction
The AUO N156HAN01.0 is a 15.6 inch FHD TFT LCD panel with a 1920×1080 resolution and 30-pin eDP interface. It is a practical display option for POS terminals, commercial equipment, industrial systems, and other applications requiring a full HD screen in a standard 15.6 inch format.
LEEHON supplies original AUO LCD panels and can also provide compatible touchscreens, cables, driver boards, and other display components according to your system requirements.
AUO N156HAN01.0 Display Specifications
| LCD Modules Brand ：AUO | Model：N156HAN01.0 |
| Power consumption：5.12W | Aspect Ratio (H:V)：16:9 |
| Resolution：1920(RGB)×1080, FHD | Backlight：WLED, 15K hrs, With LED Driver |
| Interface：eDP (2 Lanes), eDP1.2, 30 pins Connector | Work Mode：AHVA, Normally Black, Transmissive |
| Brightness： 250 cd/m² (Typ.) | Response：25ms |
| Contrast ： 800:1 | Color Depth：262K 45% NTSC |
| View Angle：85/85/85/85 (Typ.) | Surface Coating：Antiglare, Hard coating (3H) |
| Active Area (mm) ： 344.16(W)×193.59(H) mm | Work Temp：0 ~ 50 °C |
| Outline Dimension (mm)：350.66×216.15×3.2 mm | Storage Temp：-20 ~ 60 °C |
15.6 Inch Full HD Display
With a 1920 × 1080 FHD resolution, the AUO N156HAN01.0 provides a clear widescreen display for applications that require detailed interface graphics, product information, operating menus, or commercial content.
30-Pin eDP Interface
The panel uses a 30-pin eDP interface, making it suitable for systems designed around eDP display connections. Before ordering, we recommend checking the original panel’s connector position, cable configuration, mechanical dimensions, and electrical specifications to ensure compatibility.
Applications
The AUO N156HAN01.0 can be used in a range of commercial and professional display systems.
POS Equipment
The 15.6 inch FHD format is suitable for POS terminals, self-service checkout systems, payment equipment, and retail displays where a larger widescreen interface is required.
Commercial Equipment
The panel can also be considered for commercial terminals, information systems, kiosks, control equipment, and other products that require a 15.6 inch FHD LCD.
Industrial Systems
For industrial applications, the N156HAN01.0 can be integrated into equipment such as industrial PCs, HMI systems, monitoring terminals, and control systems, subject to the system’s mechanical and electrical requirements.
Why Source AUO LCD Panels from LEEHON?
LEEHON works with major LCD manufacturers and provides display sourcing and engineering support for industrial and commercial equipment manufacturers.
Original AUO LCD Panels
We supply original AUO TFT LCD panels for customers looking for reliable display quality and stable product specifications.
Display Matching Support
If you have an existing LCD model, system drawing, or equipment requirement, our team can help check the display specifications and identify a suitable replacement or compatible panel.
Complete Display Solutions
Beyond the LCD panel, LEEHON can provide related components and services, including:
- Touchscreens
- LCD cables
- Driver boards
- Interface adapter boards
- Backlight solutions
- Cover glass
- OCA / OCR / LOCA bonding
- Custom display assemblies
Engineering and Technical Support
With 16+ years of industrial LCD solutions experience, LEEHON supports customers from display selection and specification checking through quotation, sampling, customization, and production.
Frequently Asked Questions
What is the resolution of AUO N156HAN01.0?
The AUO N156HAN01.0 is a 1920 × 1080 Full HD LCD panel.
What interface does N156HAN01.0 use?
The panel uses a 30-pin eDP interface.
What size is the AUO N156HAN01.0?
It is a 15.6 inch widescreen LCD panel.
Can LEEHON provide a touchscreen for N156HAN01.0?
Yes. LEEHON can help match a suitable capacitive or resistive touchscreen and provide complete LCD + touch solutions according to the equipment requirements.
Can you check availability and quotation?
Yes. Send us the model number and required quantity at market@leehon.com, and our team can check availability and provide a quotation.
If you are sourcing the AUO N156HAN01.0 15.6 inch LCD panel, send us your requirements and we can help confirm availability, specifications, pricing, and suitable accessories.
Please provide the LCD model number, required quantity, application, and any touchscreen or assembly requirements. Our engineering team can recommend the appropriate display solution for your equipment.
